Automation, delivered as one system.

Five machines in one cell — rubber cutting, cord preparation, winding, vulcanization and stripping — linked by a six-axis robot and run by a single operator.

• Five-machine integrated production cell
• Six-axis robot transfer between stations
• Camera verification of the winding angle

In-line cutting station that cuts thin rubber sheet to a repeatable length and separates the carrier film automatically.

• Rubber thickness 0.4–1.4 mm
• Automatic length setting
• Repeatable cut dimension cycle to cycle

Winding station that lays rubber and cord fabric onto the mandrel at a controlled angle and overlap, with the cycle blocked if the material angle is wrong.

• Laser references for material alignment
• Mandrel diameter class 54–110 mm, length 900 mm
• Angle-verification interlock

Press station that cures wound mandrels under controlled heat and pressure, then unloads them to the stripping area without an operator.

• Up to four molds working in parallel
• Controlled heat and pressure cure process
• Automatic mandrel removal

Industrial press built around large-volume lift bellows molds, with the mold access and changeover designed for the product family rather than for one part.

• Press frame sized for large-volume molds
• Integrated heat and pressure process
• Industrial guarding with practical mold access

Vulcanization system where mandrels are loaded into a holder, rotated 180° into the machine and moved by a travelling holder between the process and reserve zones.

• 180° rotating loading mechanism
• Travelling mandrel holder
• Separate process and reserve zones
